Quad 125:
• MGTREFCLK0 - FMCP_HSPC_GBTCLK3_M2C_C_P/N (J22)
• MGTREFCLK1 - FMCP_HSPC_GBT1_3_M2C_C_P/N (U39)
• Four GTY transceivers allocated to FMC+ HSPC DP[12:15] (J22)
Quad 126:
• MGTREFCLK0 - FMCP_HSPC_GBT0_1_M2C_C_P/N (U40)
• MGTREFCLK1 - FMCP_HSPC_GBT1_1_M2C_C_P/N (U39)
• Four GTY transceivers allocated to FMC+ HSPC DP[4:7] (J22)
Quad 127:
• MGTREFCLK0 - FMCP_HSPC_GBTCLK4_M2C_C_P/N (J22)
• MGTREFCLK1 - FMCP_HSPC_GBT1_4_M2C_C_P/N (U39)
• Four GTY transceivers allocated to FMC+ HSPC DP[16:19] (J22)
