Working From the Setup Tab
Use the Setup tab to dene analyzer parameters.
Gas
Select the gas being sampled.
Units
Select the unit of measurement.
All values entered must be in the same unit of measure as selected.
Dewpoint Temp: This analyzer cannot be congured to read Dewpoint
output. The 4–20 mA inputs are to be used for remote Verication only.
Refer to "Conguring the 3050-DO Analyzer for Remote Verication" in
Chapter 2.
Process Pressure
Used when dewpoint C or dewpoint F is selected as unit of measure (from
the Units dropdown list).
Units
This dropdown list box allows you to specify the unit of measure for
pressure input.
Fixed
Select this if using a xed input. If selected, you must enter a xed value.
Figure 3-5.
Setup tab.
