Optional Heated Pressure Reducer Installation
Refer to Figures 2-4.1 and 2-4.2 for systems with the Heated Pressure Reducer
option.
Figure 2-4.1.
Optional Heated Pressure
Reducer Flow diagram.
SAMPLE IN
VAPOR BYPASS
SAMPLE OUT
RELIEF
RELIEF VALVE
0-400KPa (0-60psig)
PRESSURE GAUGE
REGULATOR
HEATED PRESSURE
FILTER
