PN 305725901, Rev YF
Example 3: Setting the Low Alarm Limit
Task Action
Set the analyzer to produce a “low
concentration” alarm, when the moisture
concentration falls below 0 PPM.
Write one holding register (function 06).
Register address = 67 (holding register
#40068). Value = 0.
Example 4: Enabling “Hold During Verify”
Task Action
Enable the analog outputs to “hold during
Verify” at the last measured value, when the
analyzer is Oine to perform a Verication.
Write one holding register (function 06).
Register address = 98 (holding register
#40099). Value = 1(0-track during verify,
1-hold during verify).
Example 5: Setting the High End of the Analog Output
Task Action
Setup the analog output so that a moisture
concentration of 100 PPM produces a 20 mA
current output.
Write one holding register (function 06).
Register address = 45 (holding register
#40046). Value = 100.
Example 6: Setting the Low End of the Analog Output
Task Action
Setup the analog output so that a moisture
concentration of 1 PPM produces a 4 mA
current output.
Write one holding register (function 06).
Register address = 46 (holding register
#40047). Value = 100 (multiplied by scale of
100).
Example 7: Switching to “Sensor Saver” Mode
Task Action
Set the analyzer to operate in the Sensor
Saver mode.
Write one holding register (function 06).
Register address = 99 (holding register
#40100). Value = 1 (enable sensor saver = 1,
disable sensor saver = 0).
Serial Communication Interface | 6-13
