4.0 Operating the Calibrator
4.1 Keyboard, display and standard connections
Keyboard
Fig. 3
Pos. Description

LCD.

SOFT KEYS used to select menu options displayed in the
LCD.

ENTER KEY used to accept selected options or entered
values.

NUMERIC KEYS used to type in values.
CALIBRATION INSTRUMENTS
1
2
33
4
5
6
(heading) (icon)
(information)
(functions)
