105446 06 23-03-2009 57
Note that when ON is selected, the calibrator will let
the temperature be set by the TRUE temperature. This
means it will take longer before the calibrator indicates
stable.
Note: Set follows TRUE is only relevant when the
External reference sensor is displayed in temperature
units.
Make the necessary changes and press
to accept the
new setting(s) and return to the Input menu.
Note that when SET follows TRUE is on, it is indicated by a
-symbol at the SET temperature.
Selecting the input from the sensor under test
Press
to select Sensor under test.
Press
to select type of sensor.
Press a function soft key to select a specific type of sensor.
– For voltage sensors (0 – 4V or 0 – 12V).
– For a 4 – 20mA sensor.
– For RTD sensors (Pt10, Pt50, Pt100, Pt500, Pt1000,
Cu50 or Cu100).
– For thermocouple sensors (E, J, K, L, N, R, S, T, U or
XK).
– For None (no sensor connected).
Press a function soft key to select a specific sensor and
return to the Sensor under test menu, which now displays
the selected sensor and the Convert to temperature status.
Press
to select Convert to temperature. This toggles
between Yes (where inputs are converted to temperatures)
and No (where no conversion is made). The temperature
conversion factors for the 0–4V, 0–12V and 4–20mA inputs
are set in the Temperature menu, see section 4.8.4.
Press
to accept the new settings and return to the Input
menu.
