8th Generation Advanced Amlogic TruLife Image Engine
●● Supports Dolby Vision
optional
, HDR10+, HDR10, HLG and Technicolor HDR processing
●● Motion compensated noise reduction and 3D digital noise reduction for random noise
●● Block noise, mosquito noise, spatial noise, contour noise reduction
●● Motion compensated and motion adaptive de-interlacer
●● Edge interpolation with low angle protection and processing
●● 3:2/2:2 pulldown and Video on Film (VOF) detection and processing
●● Smart sharpness with SuperScaler technology including de-contouring, de-ring, LTI, CTI, de-
jaggy, peaking
●● Dynamic non-Linear contrast enhancement
●● All dimension multiple regions smart color management including blue/green extension, flesh-
tone correction, wider gamut for video
●● 2 video planes and 3 graphics planes hardware composer
●● Independent HDR re-mapping of video and graphic layer
Video Input/Output Interface
●● MIPI-CSI camera interface with 2 lanes
●● Built-in HDMI 2.1 transmitter including both controller and PHY supporting eARC,CEC, Dynamic
HDR and HDCP 2.2, 4Kx2K@60 max resolution output
●● CVBS 480i/576i standard definition output
●● Supports all standard SD/HD/FHD video output formats: 480i/p, 576i/p, 720p, 1080i/p and
4Kx2K
●● 4-lane MIPI DSI interface, resolution up to 1920*1080
Audio Decoder and Input/Output
●● Supports MP3, AAC, WMA, RM, FLAC, Ogg,Dolby Digital
Optional
, Dolby Digital Plus
Optional
, DTS
Op-
tional
and programmable with 7.1/5.1 down-mixing
●● Low-power VAD
●● Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output, SPDIF supports
192KHz 16/24/32bit stereo
●● 3 built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x 32bits x 16ch or 96kHz x
32bits x 32ch and I2S mode up to 384kHz x 32bits x 16ch
●● Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs
●● Built-in stereo audio DAC
●● Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S
+PCM
Memory and Storage Interface
●● 32-bit DRAM memory interface with dual ranks and max 4GB total address space
●● Compatible with JEDEC standard DDR3-2133 /DDR3L-2133 /DDR4-3200 /LPDDR3-2133
/LPDDR4-3200 SDRAM
●● Supports SLC/MLC/TLC NAND Flash with 60-bit ECC, compatible to Toshiba toggle mode in ad-
dition to ONFI 2.2
●● SDSC/SDHC/SDXC card and SDIO interface with 1-bit and 4-bit data bus width supporting spec
version 2.x/3.x/4.x DS/HS modes up to UHS-I SDR104
●● eMMC and MMC card interface with 1/4/8-bit data bus width fully supporting spec version 5.0
HS400
●● Supports serial 1, 2 or 4-bit NOR Flash via SPI interface
