0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
66
Symbol Typical Current Maximum Current Note
AVDD18_USB 18.2mA 25mA -
AVDD33_USB 0.3mA 2mA -
AVDD18_DPLL 23.2mA 25mA -
VDDIO Note
Note
VDDIO=1.8V, DS=3, output 200MHz clock:
1. IO pad itself consumes about 1.4mA.
2. Driving a 55ohm trace with length of 50mm and width of 0.1mm will consumes about 2.8mA
additional current (low impedance trace consumes more power)
3. Base on #2, add 5pF cap will consumes about 1.8mA additional current, total about 6mA
4. When VDDIO=3.3V, GPIO consumes about 70% higher current,about 13mA.
5. Internal & external pull down resistor consumes more current.
5.12 Storage and Baking Conditions
The processor is moisture-sensitive device of MSL level 3, defined by IPC/JEDEC J-STD-020. Please
follow the storage and backing guidelines.
1. Calculated shelf life in sealed bag: 12 months at <40°C and <90% relative humidity (RH).
2. After bag is opened, devices that will be subjected to reflow solder or other high temperature
process must be
a. Mounted with 168 hours of factory conditions ≤30°C/60% RH, or
b. Stored per J-STD-033
3. Devices require bake, before mounting, if Humidity Indicator Card reads >10%.
4. If baking is required, refer IPC/JEDEC J-STB-033 for baking process.
S905D3 Quick Reference Manual 5 Operating Conditions
Preliminary Version
Confidential for Wesion!
