0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
64
Figure 5-22 POR Wave Diagram
Table 5-20 POR Specifications
Parameter Symbol Min. Typ. Max. Unit
Reset threshold voltage Vth 2.6 2.7 2.8 V
Reset delay time tDELAY 109 170 218 ms
5.10 Recommended Power on sequence
Example power on sequence：
S905D3 Quick Reference Manual 5 Operating Conditions
Preliminary Version
Confidential for Wesion!
