AMLOGIC S905D3 - 5.5.2 Open Drain GPIO Specifications (For DIO_OD)

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
42
Symbol Parameter Min. Typ. Max. Unit
IoL/IoH(DS=3)
1
GPIO driving
capability
4
2
- - mA
VOH Output high level
with IoL/IoH
loading
VDDIO-0.5 - - V
VOL Output low level
with IoL/IoH
loading
- - 0.4 V
Note
1. With Minimal IoL/IoH driving capability loading, IO is garanteed to meet Vol < 0.4V or VOH >
(VDDIO-0.5V) spec.
2. Maximal GPIO loading is 6mA for application such as driving LED, which does not care
about Vol/Voh spec. Please set DS=3 for such application.
3. VDD18_AO_XTAL supplies power to IOVREF.
4. Do not use this setting, it’s too weak for most applications.
5. Test condition: GPIO pin voltage close to 0V.
6. Test condition: GPIO pin voltage close to VDDIO(3.3V).
5.5.2 Open Drain GPIO Specifications (For DIO_OD)
Symbol Parameter Min. Typ. Max. Unit
V
iH(
OD5V) High-level input
voltage
1.5 5.5 V
V
iL(
OD5V) Low-level input
voltage
-0.3 0.8 V
V
iH(
OD3.3V) High-level input
voltage
1.5 3.6 V
V
iL(
OD3.3V) Low-level input
voltage
-0.3 0.8 V
R
PU/PD
No built-in pull
up/down resistor
on OD IO
- - - ohm
Io OD IO driving
low capability
4 6 mA
VOL Output low level
with min Io
loading
0.4 V
Note
1. With Minimal IoL driving capability loading, IO is guaranteed to meet Vol<0.4V spec
2. Maximal GPIO loading is 6mA for application such as driving LED, which does not care
about Vol spec
3. The V
iL
/ V
iH
of OD PAD is irrelevant to VDDIO voltage.
