Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
AVSS_
CVBS
AP Ground of CVBS digital-analog converter - To GND
Digital Power
VDDCPU P - Power supply for CPU (Cortex A55) - To
VDDCP-
U
VDDQ P - DDR IO Power supply for DDR PHY - To
VDDQ
VDD_DDR P - Core Power supply for DDR PHY - To VDD_
EE
VDD_EE P - Power supply for GPU and core logic - To VDD_
EE
VDD18_
AO_XTAL
P - 1.8V Power supply for Always On Domain - To
VDD18_
AO_
XTAL
Digital Ground
DVSS P - Digital power ground - To GND
Abbreviations:
●● DI = Digital input pin
●● DO = Digital output pin
●● DIO = Digital input/output pin
●● OD 5V = 5V input tolerant open drain (OD) output pin, need external pull up
●● A = Analog setting or filtering pin
●● AI = Analog input pin
●● AO = Analog output pin
●● AIO = Analog input/output pin
●● P = Power pin
●● AP = Analog power pin
●● NC = No connection
●● UP = Pull-Up
●● DOWN = Pull-down
●● Z = High-Z
4.4 Pin Multiplexing Tables
Multiple usage pins are used to conserve pin consumption for different features. The devices can be
used in many different applications but each application will not utilize all the on chip features. As a
result, some of the features share the same pin. Most of the multiple usage pins can be used as a
GPIO pin as well.
