AMLOGIC S905D3 - Pin Description

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
13
BALL # NET NAME
BK46 GPIOZ_7
BM1 DDR_DQSP0
BM3 DVSS
BM5 DDR_DQ2
BM7 DDR_DQ0
BM11 DVSS
BALL # NET NAME
BM15 BOOT_5
BM19 BOOT_13
BM24 GPIOX_18
BM28 DVSS
BM32 GPIOX_0
BM36 GPIOX_4
BALL # NET NAME
BM40 DVSS
BM42 GPIOZ_3
BM44 GPIOZ_4
BM46 DVSS
4.3 Pin Description
The S905D3 application processor pin assignment is described in the following table.
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
GPIOZ - Refer to
Table 4-1 for functional multiplex information.
GPIOZ_0 DIO Up General purpose input/output bank Z signal 0 VDDIO_Z NC
GPIOZ_1 DIO Up General purpose input/output bank Z signal 1 VDDIO_Z NC
GPIOZ_2 DIO Up General purpose input/output bank Z signal 2 VDDIO_Z NC
GPIOZ_3 DIO Up General purpose input/output bank Z signal 3 VDDIO_Z NC
GPIOZ_4 DIO Up General purpose input/output bank Z signal 4 VDDIO_Z NC
GPIOZ_5 DIO Up General purpose input/output bank Z signal 5 VDDIO_Z NC
GPIOZ_6 DIO Up General purpose input/output bank Z signal 6 VDDIO_Z NC
GPIOZ_7 DIO Up General purpose input/output bank Z signal 7 VDDIO_Z NC
GPIOZ_8 DIO Up General purpose input/output bank Z signal 8 VDDIO_Z NC
GPIOZ_9 DIO Down General purpose input/output bank Z signal 9 VDDIO_Z NC
GPIOZ_10 DIO Down General purpose input/output bank Z signal
10
VDDIO_Z NC
GPIOZ_11 DIO Down General purpose input/output bank Z signal
11
VDDIO_Z NC
GPIOZ_12 DIO Down General purpose input/output bank Z signal
12
VDDIO_Z NC
GPIOZ_13 DIO Down General purpose input/output bank Z signal
13
VDDIO_Z NC
GPIOZ_14 OD 5V Z General purpose input/output bank Z signal
14
VDDIO_Z NC
GPIOZ_15 OD 5V Z General purpose input/output bank Z signal
15
VDDIO_Z NC
VDDIO_Z P - Power supply for GPIO bank Z - NC
GPIOA - Refer to
Table 4-2 for functional multiplex information.
GPIOA_0 DIO Down General purpose input/output bank A signal 0 VDDIO_A NC
GPIOA_1 DIO Down General purpose input/output bank A signal 1 VDDIO_A NC
GPIOA_2 DIO Down General purpose input/output bank A signal 2 VDDIO_A NC
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
