AMLOGIC S905D3 - Page 19

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
14
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
GPIOA_3 DIO Down General purpose input/output bank A signal 3 VDDIO_A NC
GPIOA_4 DIO Down General purpose input/output bank A signal 4 VDDIO_A NC
GPIOA_5 DIO Down General purpose input/output bank A signal 5 VDDIO_A NC
GPIOA_6 DIO Down General purpose input/output bank A signal 6 VDDIO_A NC
GPIOA_7 DIO Down General purpose input/output bank A signal 7 VDDIO_A NC
GPIOA_8 DIO Down General purpose input/output bank A signal 8 VDDIO_A NC
GPIOA_9 DIO Down General purpose input/output bank A signal 9 VDDIO_A NC
GPIOA_10 DIO Down General purpose input/output bank A signal
10
VDDIO_A NC
GPIOA_11 DIO Down General purpose input/output bank A signal
11
VDDIO_A NC
GPIOA_12 DIO Down General purpose input/output bank A signal
12
VDDIO_A NC
GPIOA_13 DIO Down General purpose input/output bank A signal
13
VDDIO_A NC
GPIOA_14 DIO Up General purpose input/output bank A signal
14
VDDIO_A
NC
GPIOA_15 DIO Up General purpose input/output bank A signal
15
VDDIO_A
NC
VDDIO_A P - Power supply for GPIO bank A - NC
BOOT - Refer to
Table 4-3 for functional multiplex information.
BOOT_0 DIO UP General purpose input/output bank BOOT
signal 0
VDDIO_
BOOT
NC
BOOT_1 DIO UP General purpose input/output bank BOOT
signal 1
VDDIO_
BOOT
NC
BOOT_2 DIO UP General purpose input/output bank BOOT
signal 2
VDDIO_
BOOT
NC
BOOT_3 DIO UP General purpose input/output bank BOOT
signal 3
VDDIO_
BOOT
NC
BOOT_4 DIO UP General purpose input/output bank BOOT
signal 4
VDDIO_
BOOT
NC
BOOT_5 DIO UP General purpose input/output bank BOOT
signal 5
VDDIO_
BOOT
NC
BOOT_6 DIO UP General purpose input/output bank BOOT
signal 6
VDDIO_
BOOT
NC
BOOT_7 DIO UP General purpose input/output bank BOOT
signal 7
VDDIO_
BOOT
NC
BOOT_8 DIO UP General purpose input/output bank BOOT
signal 8
VDDIO_
BOOT
NC
BOOT_9 DIO UP General purpose input/output bank BOOT
signal 9
VDDIO_
BOOT
NC
BOOT_10 DIO UP General purpose input/output bank BOOT
signal 10
VDDIO_
BOOT
NC
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
