Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
BOOT_11 DIO UP General purpose input/output bank BOOT
signal 11
VDDIO_
BOOT
NC
BOOT_12 DIO DOWN General purpose input/output bank BOOT
signal 12
VDDIO_
BOOT
NC
BOOT_13 DIO DOWN General purpose input/output bank BOOT
signal 13
VDDIO_
BOOT
NC
BOOT_14 DIO UP General purpose input/output bank BOOT
signal 14
VDDIO_
BOOT
NC
BOOT_15 DIO UP General purpose input/output bank BOOT
signal 15
VDDIO_
BOOT
NC
VDDIO_
BOOT
P - Power supply for GPIO bank BOOT - To
VDDIO_
BOOT
GPIOC - Refer to
Table 4-4 for functional multiplex information.
GPIOC_0 DIO UP General purpose input/output bank C signal 0 VDDIO_C NC
GPIOC_1 DIO UP General purpose input/output bank C signal 1 VDDIO_C NC
GPIOC_2 DIO UP General purpose input/output bank C signal 2 VDDIO_C NC
GPIOC_3 DIO UP General purpose input/output bank C signal 3 VDDIO_C NC
GPIOC_4 DIO UP General purpose input/output bank C signal 4 VDDIO_C NC
GPIOC_5 DIO UP General purpose input/output bank C signal 5 VDDIO_C NC
GPIOC_6 DIO UP General purpose input/output bank C signal 6 VDDIO_C NC
GPIOC_7 OD 5V Z General purpose input/output bank C signal 7 VDDIO_C NC
VDDIO_C P - Power supply for GPIO bank C - NC
GPIOX - Refer to
Table 4-5 for functional multiplex information.
GPIOX_0 DIO Up General purpose input/output bank X signal 0 VDDIO_X NC
GPIOX_1 DIO Up General purpose input/output bank X signal 1 VDDIO_X NC
GPIOX_2 DIO Up General purpose input/output bank X signal 2 VDDIO_X NC
GPIOX_3 DIO Up General purpose input/output bank X signal 3 VDDIO_X NC
GPIOX_4 DIO Up General purpose input/output bank X signal 4 VDDIO_X NC
GPIOX_5 DIO Up General purpose input/output bank X signal 5 VDDIO_X NC
GPIOX_6 DIO Down General purpose input/output bank X signal 6 VDDIO_X NC
GPIOX_7 DIO Up General purpose input/output bank X signal 7 VDDIO_X NC
GPIOX_8 DIO Up General purpose input/output bank X signal 8 VDDIO_X NC
GPIOX_9 DIO Up General purpose input/output bank X signal 9 VDDIO_X NC
GPIOX_10 DIO Up General purpose input/output bank X signal
10
VDDIO_X NC
GPIOX_11 DIO Up General purpose input/output bank X signal
11
VDDIO_X NC
