AMLOGIC S905D3 - Page 21

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
16
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
GPIOX_12 DIO Up General purpose input/output bank X signal
12
VDDIO_X NC
GPIOX_13 DIO Up General purpose input/output bank X signal
13
VDDIO_X NC
GPIOX_14 DIO Up General purpose input/output bank X signal
14
VDDIO_X NC
GPIOX_15 DIO Up General purpose input/output bank X signal
15
VDDIO_X NC
GPIOX_16 DIO Up General purpose input/output bank X signal
16
VDDIO_X NC
GPIOX_17 DIO Down General purpose input/output bank X signal
17
VDDIO_X NC
GPIOX_18 DIO Up General purpose input/output bank X signal
18
VDDIO_X NC
GPIOX_19 DIO Z General purpose input/output bank X signal
19
VDDIO_X NC
VDDIO_X P - Power supply for GPIO bank X - NC
GPIOH - Refer to
Table 4-6 for functional multiplex information.
GPIOH_0 OD5V Z General purpose input/output bank H signal 0 VDDIO_H NC
GPIOH_1 OD5V Z General purpose input/output bank H signal 1 VDDIO_H NC
GPIOH_2 OD5V Z General purpose input/output bank H signal 2 VDDIO_H NC
GPIOH_3 OD5V Z General purpose input/output bank H signal 3 VDDIO_H NC
GPIOH_4 DIO DOWN General purpose input/output bank H signal 4 VDDIO_H NC
GPIOH_5 DIO DOWN General purpose input/output bank H signal 5 VDDIO_H NC
GPIOH_6 DIO DOWN General purpose input/output bank H signal 6 VDDIO_H NC
GPIOH_7 DIO DOWN General purpose input/output bank H signal 7 VDDIO_H NC
GPIOH_8 OD5V Z General purpose input/output bank H signal 8 VDDIO_H NC
VDDIO_H P - Power supply for GPIO bank H - NC
GPIOAO - Refer to
Table 4-7 for functional multiplex information.
GPIOAO_0 DIO Up General purpose input/output bank AO signal
0
VDDIO_AO NC
GPIOAO_1 DIO Up General purpose input/output bank AO signal
1
VDDIO_AO NC
GPIOAO_2 DIO Down General purpose input/output bank AO signal
2
VDDIO_AO NC
GPIOAO_3 DIO Up General purpose input/output bank AO signal
3
VDDIO_AO NC
GPIOAO_4 DIO Down General purpose input/output bank AO signal
4
VDDIO_AO NC
GPIOAO_5 DIO Up General purpose input/output bank AO signal
5
VDDIO_AO NC
GPIOAO_6 DIO Down General purpose input/output bank AO signal
6
VDDIO_AO NC
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
