AMLOGIC S905D3 - Page 34

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
29
Pin Name Func1 Func2 Func3 Func4 Func5 Func6 Func7
GPIOX_17 I2C_EE_
M2_SDA
GPIOX_18 I2C_EE_
M2_SCL
GPIOX_19 PWM_B WORLD_
SYNC
GEN_CLK_
EE
Table 4-6 GPIOH_x Multi-Function Pin
Pin Name Func1 Func2 Func3 Func4 Func5 Func6
GPIOH_0 HDMITX_
SDA
I2C_EE_M3_
SDA
GPIOH_1 HDMITX_SCL I2C_EE_M3_
SCL
GPIOH_2 HDMITX_
HPD_IN
I2C_EE_M1_
SDA
GPIOH_3 I2C_EE_M1_
SCL
AO_CEC_A AO_CEC_B
GPIOH_4 SPDIF_OUT UART_EE_
C_RTS
SPI_B_MOSI
GPIOH_5 SPDIF_IN UART_EE_
C_CTS
SPI_B_MISO PWM_F TDMB_D3 TDMB_DIN3
GPIOH_6 ISO7816_
CLK
UART_EE_
C_RX
SPI_B_SS0 I2C_EE_M1_
SDA
IR_
REMOTE_
OUT
GPIOH_7 ISO7816_
DATA
UART_EE_
C_TX
SPI_B_SCLK I2C_EE_M1_
SCL
PWM_B
GPIOH_8
Table 4-7 GPIOAO_x Multi-Function Pin
Pin Name Func1 Func2 Func3 Func4 Func5 Func6 Func7
GPIOAO_0 UART_AO_
A_TX
GPIOAO_1 UART_AO_
A_RX
GPIOAO_2 I2C_AO_
M0_SCL
UART_AO_
B_TX
I2C_AO_
S0_SCL
GPIOAO_3 I2C_AO_
M0_SDA
UART_AO_
B_RX
I2C_AO_
S0_SDA
GPIOAO_4 IR_
REMOTE_
OUT
CLK_32K_
IN
PWMAO_C PWMAO_
C_HIZ
TDMB_D0 TDMB_
DIN0
GPIOAO_5 IR_
REMOTE_
INPUT
PWMAO_D
GPIOAO_6 JTAG_A_
CLK
PWMAO_C TSIN_A_
SOP
TDMB_D2 TDMB_
DIN2
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
