Pin Name Func1 Func2 Func3 Func4 Func5 Func6 Func7
GPIOAO_7 JTAG_A_
TMS
TSIN_A_
DIN0
TDMB_FS TDMB_
SLV_FS
GPIOAO_8 JTAG_A_
TDI
UART_AO_
B_TX
TSIN_A_
CLK
TDMB_
SCLK
TDMB_
SLV_SCLK
GPIOAO_9 JTAG_A_
TDO
IR_
REMOTE_
OUT
UART_AO_
B_RX
TSIN_A_
VALID
MCLK_0
GPIOAO_
10
AO_CEC_A AO_CEC_B PWMAO_D SPDIF_
OUT
TDMB_D1 TDMB_
DIN1
CLK12_24
GPIOAO_
11
PWMAO_
A_HIZ
PWMAO_A GEN_CLK_
EE
GEN_CLK_
AO
Table 4-8 GPIOE_x Multi-Function Pin
Pin Name Func1 Func2 Func3 Func4
GPIOE_0 UART_AO_A_CTS UART_AO_B_CTS PWMAO_B I2C_AO_M0_SCL
GPIOE_1 UART_AO_A_RTS UART_AO_B_RTS PWMAO_D I2C_AO_M0_SDA
GPIOE_2 CLK12_24 CLK25_EE PWM_A
Table 4-9 DDR AC Multi-Function Pin
Pin Name LPDDR3 LPDDR4 DDR3 DDR4
AC_0 CKEA0 CKEA0 CKE0 CKE0
AC_1 CKEA1 CKEA1 CKE1 CKE1
AC_2 CSA0 CSA0 CS_N0 CS_N0
AC_3 CSA1 CSA1 NC NC
AC_4 CLKA_T CLKA_T CAS_N A6
AC_5 CLKA_C CLKA_C BA2 A8
AC_6 NC NC A7 A2
AC_7 NC NC A5 A11
AC_8 CAA2 CAA2 A10 A10
AC_9 CAA7 CAA3 WE_N BG1
AC_10 CAA1 CAA1 A0 A3
AC_11 CAA4 CAA0 A2 A12
AC_12 CAA5 CAA5 A9 A0
AC_13 CAA6 CAA4 A13 A4
AC_14 CAA0 NC A14 A13
AC_15 CAA3 NC A11 A9
AC_16 CAA9 NC CLK0_T CLK0_T
AC_17 CAA8 NC CLK0_C CLK0_C
AC_18 ODTA NC NC NC
