AMLOGIC S905D3 - Page 17

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
12
BALL # NET NAME
AW24 DVSS
AW26 VDD_EE
AW28 DVSS
AW30 DVSS
AW32 VDDIO_Z
AW34 VDDIO_H
AY3 DDR_DQ10
AY5 DDR_DQ9
AY7 DVSS
AY9 DDR_DQ13
AY11 DVSS
AY36 VDDIO_AO
AY38 SARADC_CH0
AY40 SARADC_CH1
AY42 SYS_OSCIN
AY44 DVSS
BB1 DDR_DQSP1
BB3 DDR_DQSN1
BB5 DVSS
BB10 DVSS
BB13 DVSS
BB16 DVSS
BB19 BOOT_10
BB22 DVSS
BB25 DVSS
BB28 GPIOE_0
BB31 DVSS
BB34 GPIOX_8
BB42 GPIOZ_15
BB44 SYS_OSCOUT
BB46 DVSS
BC7 DVSS
BC36 GPIOZ_1
BC38 SARADC_CH2
BC40 SARADC_CH3
BD3 DDR_DQ8
BD5 DDR_DQ7
BALL # NET NAME
BD10 DVSS
BD13 GPIOAO_5
BD16 GPIOAO_4
BD19 BOOT_11
BD22 DVSS
BD25 DVSS
BD28 GPIOE_1
BD31 GPIOX_10
BD34 GPIOX_9
BD42 GPIOZ_12
BD44 GPIOZ_13
BF1 DDR_DQ6
BF3 DVSS
BF5 DDR_DQ5
BF7 DVSS
BF10 DVSS
BF13 GPIOAO_3
BF16 GPIOAO_11
BF19 BOOT_15
BF22 BOOT_9
BF25 VDDIO_X
BF28 TEST_N
BF31 GPIOX_17
BF34 GPIOX_11
BF36 GPIOZ_0
BF39 GPIOZ_14
BF42 GPIOZ_9
BF44 GPIOZ_11
BF46 GPIOZ_10
BH1 DVSS
BH3 DDR_DQ4
BH5 DVSS
BH7 DVSS
BH9 BOOT_1
BH11 BOOT_3
BH13 BOOT_4
BALL # NET NAME
BH17 BOOT_6
BH19 DVSS
BH21 VDDIO_BOOT
BH24 BOOT_8
BH26 GPIOX_19
BH28 GPIOX_14
BH30 GPIOX_13
BH32 DVSS
BH34 GPIOX_3
BH36 DVSS
BH38 DVSS
BH40 GPIOX_7
BH42 GPIOZ_6
BH44 DVSS
BH46 GPIOZ_8
BK1 DDR_DQM0
BK3 DDR_DQSN0
BK5 DDR_DQ3
BK7 DDR_DQ1
BK9 BOOT_0
BK11 BOOT_2
BK13 DVSS
BK15 DVSS
BK17 BOOT_7
BK19 BOOT_14
BK21 BOOT_12
BK24 DVSS
BK26 GPIOX_15
BK28 GPIOX_12
BK30 GPIOX_16
BK32 GPIOX_1
BK34 GPIOX_2
BK38 GPIOX_5
BK40 GPIOX_6
BK42 GPIOZ_2
BK44 GPIOZ_5
