AMLOGIC S905D3 - Page 16

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
11
BALL # NET NAME
AF16 VDDQ
AF18 DVSS
AF20 DVSS
AF22 AVSS_AMPLL
AF24 DVSS
AF26 VDD_EE
AF28 VDD_EE
AF30 DVSS
AF32 AVDD18_MIPICSI
AF34 AVDD18_MIPIDSI
AG1 AC_15
AG3 AC_14
AG5 AC_23
AG42 DVSS
AG46 DSI_D0P
AH7 AC_13
AH9 DVSS
AH11 AC_9
AH14 AVDD_DDRPLL
AH17 VDD_DDR
AH20 VDDCPU
AH23 AVDD18_DPLL
AH26 VDD_EE
AH29 DVSS
AH32 DVSS
AH36 DVSS
AH38 CSI_D0N
AH40 CSI_D0P
AH44 DSI_D0N
AK1 AC_11
AK3 AC_10
AK5 DVSS
AK13 DVSS
AK15 VDDQ
AK17 DVSS
AK19 VDDCPU
AK21 VDDCPU
BALL # NET NAME
AK23 DVSS
AK25 DVSS
AK27 VDD_EE
AK29 VDD_EE
AK31 DVSS
AK33 AVDD18_SARADC
AK42 DVSS
AK44 DSI_D1P
AK46 DSI_D1N
AL7 AC_17
AL9 AC_16
AL11 AC_3
AL36 DSI_CEXT
AL38 DSI_R1K
AL40 DSI_R600
AM3 AC_2
AM5 AC_36
AM27 VDD_EE
AM42 DSI_D2N
AM44 DSI_D2P
AN14 DVSS
AN16 DVSS
AN18 DVSS
AN20 VDDCPU
AN22 VDDCPU
AN24 DVSS
AN30 DVSS
AN32 VDD18_AO_XTAL
AN34 DVSS
AP1 AC_0
AP3 DVSS
AP5 AC_18
AP7 DDR_DQM1
AP9 DDR_DQ15
AP11 AC_1
AP27 VDD_EE
BALL # NET NAME
AP36 GPIOAO_0
AP38 GPIOAO_1
AP40 DVSS
AP42 DVSS
AP44 DSI_D3P
AP46 DSI_D3N
AT3 DVSS
AT5 AC_8
AT13 DVSS
AT15 DVSS
AT17 VDDCPU
AT19 VDDCPU
AT21 VDDCPU
AT23 DVSS
AT25 DVSS
AT27 VDD_EE
AT33 DVSS
AT42 GPIOAO_8
AT44 GPIOAO_9
AU9 DDR_DQ12
AU11 DVSS
AU29 DVSS
AU31 DVSS
AU36 GPIOAO_10
AU38 GPIOE_2
AU40 GPIOAO_2
AV1 DVSS
AV3 DDR_DQ14
AV5 DDR_DQ11
AV42 RESET_N
AV44 GPIOAO_6
AV46 GPIOAO_7
AW14 DVSS
AW16 VDDCPU
AW18 VDDCPU
AW20 VDDCPU
AW22 VDDCPU
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
