AMLOGIC S905D3 - Page 15

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
10
BALL # NET NAME
L44 HDMITX_CKP
N3 DVSS
N5 AC_35
N7 DVSS
N9 AC_31
N11 DVSS
N15 VDDQ
N36 GPIOH_2
N38 VMID
N40 AVSS_AUDIO
N42 LOLP
N44 DVSS
P13 VDDQ
P18 DVSS
P20 DVSS
P22 DVSS
P24 AVDD18_PCIE
P26 AVDD18_ENET
P28 AVDD33_USB
P30 DVSS
P32 AVSS_HPLL
P34 DVSS
R1 DVSS
R3 AC_34
R5 AC_20
R15 DVSS
R42 LORN
R44 LOLN
R46 LORP
T7 AC_38
T9 DDR_RSTn
T11 DVSS
T36 REFP
T38 CVBS_RSET
T40 CVBS_VREF
U3 AC_21
U5 DVSS
BALL # NET NAME
U13 VDDQ
U15 DVSS
U17 DVSS
U19 VDD_DDR
U21 DVSS
U23 DVSS
U25 AVDD18_USB
U27 ENET_ATP
U29 AVSS_ENETPLL
U31 NC
U33 DVSS
U42 DVSS
U44 CVBS_IOUT
W1 AC_33
W3 AC_29
W5 AC_32
W7 AC_37
W9 AC_30
W11 PVREF
W36 CVBS_COMP
W38 GPIOH_5
W40 GPIOH_4
W42 DVSS
W44 eARC_P
W46 eARC_N
Y14 VDDQ
Y16 DVSS
Y18 DVSS
Y20 VDD_EE
Y22 DVSS
Y24 AVSS_HCSL
Y26 DVSS
Y28 AVDD0V8_USB_PCIE
Y30 AVDD0V8_HDMI
Y32 AVDD18_HDMI
Y34 AVSS_CVBS
AA3 AC_25
BALL # NET NAME
AA5 AC_24
AA42 NC
AA44 NC
AB7 AC_5
AB9 AC_4
AB11 PZQ
AB36 CSI_CLKA_P
AB38 GPIOH_7
AB40 DVSS
AC1 AC_28
AC3 DVSS
AC5 AC_22
AC13 DVSS
AC15 VDDQ
AC17 DVSS
AC19 VDD_DDR
AC21 DVSS
AC23 DVSS
AC25 DVSS
AC27 VDD_EE
AC29 DVSS
AC31 AVDD18_AUDIO
AC33 AVDD18_CVBS
AC42 DVSS
AC44 NC
AC46 NC
AE3 DVSS
AE5 AC_26
AE7 AC_6
AE9 AC_7
AE11 AC_12
AE36 CSI_CLKA_N
AE38 CSI_D1N
AE40 CSI_D1P
AE42 DSI_CLKN
AE44 DSI_CLKP
AF14 DVSS
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
