AMLOGIC S905D3 - Page 28

0.6 (2019–07–25)
Amlogic Proprietary and Confidential
Copyright © Amlogic. All rights reserved.
23
Net Name Type Default
Pull UP/
DN
Description Power
Domain
If
Unused
DSI_D1N AO - MIPI DSI data1 negative output AVDD18_
DSI
NC
DSI_D1P AO - MIPI DSI data1 positive output AVDD18_
DSI
NC
DSI_D2N AO - MIPI DSI data2 negative output AVDD18_
DSI
NC
DSI_D2P AO - MIPI DSI data2 positive output AVDD18_
DSI
NC
DSI_D3N AO - MIPI DSI data3 negative output AVDD18_
DSI
NC
DSI_D3P AO - MIPI DSI data3 positive output AVDD18_
DSI
NC
DSI_R1K A - MIPI DSI reference current setting resistor
with 1K ohm
AVDD18_
DSI
NC
DSI_R600 A - MIPI DSI reference voltage setting resistor
with 604 ohm
AVDD18_
DSI
NC
AVDD18_
MIPIDSI
AP - MIPI-DSI power supply - To 1.8V
CSI
CSI_D0_N AIO - MIPI CSI data 0 negative input AVDD18_
MIPICSI
NC
CSI_D0_P AIO - MIPI CSI data 0 positive input AVDD18_
MIPICSI
NC
CSI_D1_N AI - MIPI CSI data 1 negative input AVDD18_
MIPICSI
NC
CSI_D1_P AI - MIPI CSI data 1 positive input AVDD18_
MIPICSI
NC
CSI_CLKA_
N
AI - MIPI CSI CLK negative input for channel A AVDD18_
MIPICSI
NC
CSI_CLKA_
P
AI - MIPI CSI CLK positive input for channel A AVDD18_
MIPICSI
NC
AVDD18_
MIPICSI
AP - MIPI-CSI power supply - To 1.8V
Audio DAC
LOLN AO - Audio DAC line-out left channel negative
signal
AVDD18_
Audio
NC
LOLP AO - Audio DAC line-out left channel positive
signal
AVDD18_
Audio
NC
LORN AO - Audio DAC line-out right channel negative
signal
AVDD18_
Audio
NC
LORP AO - Audio DAC line-out right channel positive
signal
AVDD18_
Audio
NC
REFP A - Audio DAC positive reference voltage AVDD18_
Audio
NC
VMID A - Audio DAC external filter cap connection AVDD18_
Audio
NC
S905D3 Quick Reference Manual 4 Pinout Specification
Preliminary Version
Confidential for Wesion!
