Figure 5-9 Async Waveform for Address Output Cycle
Figure 5-10 Async Waveform for Sequential Data Read Cycle(After Read)-EOD Mode
Table 5-8 Nand Timing Specifications
Symbol Parameter (-
Asynchronous) (-
mode 5)
Min Max Unit
tCLS CLE setup time 10 - ns
tCLH CLE hold time 5 - ns
tALS ALE setup 10 - ns
