H-1.601.00149-2.0
Page
26
Fig. 24 Remove upper part
7. After removing the upper part, press the “On/Off” button to activate
the device in advance to save boot time, and move close to the patient.
Fig. 25 Start device in advance
8. Stop manual CPR
9. After aligning the leg locks with the back panel latch slots, insert the
UPPER part into the back plate and you will hear a click.
