H-1.601.00149-2.0
Page
27
Fig. 25 Install
10. Pull up once to make sure the parts are connected correctly.
Note:
• [Pull up and confirm the grip position] When lifting up, please note that
the position where the hand is placed is the upper gripper hole without
the lock button, so as not to loosen the lock.
Fig. 27 Hand holding postion
Warning：
• [Patient too large] If the patient is too large, the upper part of the E6
cannot be locked to the back panel without pressing the patient's chest.
Please abandon using the E6 under such case and continue manual CPR.
