Ampler Stellar - Handlebar; Brakes; Saddle and Seatpost; Wheels

Ampler – Stellar / Stout 16Ampler Pedelec
4.1.4 Brakes
The Pedelec is equipped with a front wheel brake and a rear wheel
brake. Get familiar with your brake system and pay attention to
the brake lever designations. Always check which brake lever
operates which brake before you start your ride. Both brakes are
hydraulically actuated disc brakes. The reach adjustment screw
can be used to change the distance of the brake lever blade to
the handlebar.
1 Brake lever blade
2 Reach adjustment screw
3 Brake hose
4 Clamping screw
4.1.5 Saddle and Seatpost
The saddle is adjustable in height and tilt angle.
1 Saddle
2 Seatpost
3 Saddle clamp (5 mm hex sockets, key not included)
4 Seat tube
5 Seatpost clamp (4 mm hex socket)
4.1.6 Wheels
The wheels consist of the rim with spokes and hub, the brake discs and the tires, as well as the rear cassette for the chain drive.
The tires are equipped with reective sidewalls. The electric motor is integrated into the hub of the rear wheel and transmits its
torque via a planetary gears and clutch system. The clutch automatically disengages when the motor is o or when the speed
of the rear wheel exceeds that of the motor (above 25 km/h).
4.1.3 Handlebar
1 Handlebar
2 Stem
3 Grips
4 Bell
5 Brake levers
6 Shifter
