Ampler – Stellar / Stout 26Before the first ride
Adjusting the saddle height
1. Slightly loosen the seatpost clamp on the seat tube with
a 4 mm hex key.
2. Move the seatpost to a point where the top of the saddle is
approximately at the height of your hip joint and tighten
the seatpost clamp.
3. Position the Pedelec in such a way that it is possible to sit on
it and support you (e.g. leaning against a wall). Do not sit on
the bike leaning on the kickstand.
4. Move one pedal to the lowest position.
5. Place your heel on the pedal.
6. Your leg should be straight with your knee joint still
slightly bent.
7. If necessary, repeat the process and adjust the saddle
height so that the leg is almost fully extended but not
stretched when the heel is on the pedal.
y Adjust the seatpost height until the position feels right.
y Do not pull out the seatpost further than the minimum
insertion mark.
8. Check again for the correct height.
9. Check and tighten the seatpost clamp.
6.2.2 Adjusting the lighting system (light beam of the front light)
The Pedelec's light beam is preset at the factory for proper illumination of the road.
Two TX20 keys are required to adjust the front light (not included; available from specialist shops and tool stores).
