17 Ampler Pedelec Ampler – Stellar / Stout
4.1.7 Lighting system
The Pedelec is equipped with a front light mounted to the fork crown and a rear light integrated into the rear fender.
The front and rear reector must be attached during assembly. The front and rear lights are powered by the battery.
1 Front light
2 Front reector
3 Rear light
4 Rear reector
Even if the battery power is low and the electric drive shuts o, the lights remain on for sucient time to bring you home.
4.1.8 Electric drive
The Pedelec is equipped with an electric drive that assists the ride with 2 selectable assist modes up to the max. speed of 25 km/h.
The power button is used to switch the Pedelec on before riding, to select the assist mode if required, to switch the lights on/o and
to switch the Pedelec o after riding. The modes are shown on the display.
The drive has a Li-ion battery as power source, an electric motor and sensors that measure speed, cadence and torque.
The motor output adjusts accordingly to the selected assist mode and the torque sensor signal.

The battery, the electronics and the sensors are integrated into the Pedelec's down tube and bottom bracket.

The motor and the hub of the rear wheel form an integrated unit.
The Pedelec can be used with or without motor assist.
1 Rear wheel
2 Motor cable
3 Integrated motor
