AMPTRON Ai205 - Display panel and keys

Detail man-machine interface will be discripted in this chapter. This includes
how to get the electric metering data and how to do the parameter setting.
Display panel and keys
There are one display panel and four keys in the front of Ai205. All the display
segments are illustrated in fig 3.1.
30
Table 3.1 Display Panel discription
Fig 3.1 All Display Segments
3
4
5
6
7
9
8
10
11
2
12
113
Discription
Display metering data
Voltage, current, power, power factor, frequency, THD,
demand, unbalance factor, max, min etc.
Energy data display or real time clock
Display load current percentage
Display
Four lines of letter in the
metering area
One line of letter in the
energy display area
Load rating
SN
1
2
3
