AMPTRON Ai205 - Appendix A Technical data and specifications

Voltage input
Voltage rating -100V option 100Vac nominal F.S.input,Vln
with 20% overrang(3LN or 2LN)
100Vac nominal F.S.input,VLL
with 20% overrang(2LL)
-400V option 400Vac nominal F.S.inpu,VLL
with 20% overrang
Frequency range 45～65Hz
Overload 2 times for continue 2500Vac for
1 Sec (None recurrence)
Voltage range through PT 500KV highest at primary side
PT burden <0.2VA
Measuring True RMS
Current input
Current rating 5Amp 5Amp AC nominal F.S.
Ordering on input with 20% overrang
special rating
Current range 10000A highest at primary side
Overload 10A for continue
100A for 1 Sec (None recurrence)
CT burden < 0.1VA
Measuring True RMS
94
Appendix A Technical data and specifications
(for 3 phase, 2 phase and single phase)
Input Ratings
