Alarm Recording
Function code: 03 for Reading
Table 4.22 Alarming setting table
87
Register associated 9
th
inequality with
one of the 34 variables, var9
Relation symbol selecting register,
INEQU_sign9
Limit value for 9
th
inequality, Ref9
0~34
0:< low limit
1:> up limit
Related with variable
Integer
Integer
Word or Integer
034CH
034DH
034EH
R/W
R/W
R/W
0354H Over limit Status of the 9 inequalities Bit0~8 corresponding
to 1
st
~9th inequality
0: No 1: Yes Integer R
0355H Variable Number of the 1
st
Alarm record 0~34 word R
0356H Variable Value of the 1
st
Alarm Record -32768~32767 Integer R
0357H Year of 1
st
Alarm Record 2000~2099 word R
0358H Month of 1
st
Alarm Record 1~12 word R
0359H Date of 1
st
Alarm Record 1~31 word R
035AH Hour of 1
st
Alarm Record 0~23 word R
035BH Minute of 1
st
Alarm Record 0~59 word R
035CH Second of 1
st
Alarm Record 0~59 word R
035DH Variable Number of the 2
nd
Alarm record 0~34 word R
035EH Variable Value of the 2
nd
Alarm Record -32768~32767 Integer R
035FH Year of 2
nd
Alarm Record 2000~2099 word R
0360H Month of 2
nd
Alarm Record 1~12 word R
0361H Date of 2
nd
Alarm Record 1~31 word R
0362H Hour of 2
nd
Alarm Record 0~23 word R
0363H Minute of 2
nd
Alarm Record 0~59 word R
0364H Second of 2
nd
Alarm Record 0~59 word R
Addr. Parameter Range Object Type of
Type access
