AMPTRON Ai205 - Power Quality Measurements; Energy Data Converting Table

To Next Page

To Previous Page

Power Quality Measurements

Function code: 03

Parameter Relationship Unit

Energy Ep_imp, Ep_exp, Ep_total, Ep_net Ep=Rx / 10 Kwh

Reactive Energy Eq_imp,Eq_exp,Eq_total,Eq_net Eq=Rx / 10 Kvarh

Power Quality Measurements

Function code: 03

Address Parameter Range Object Type of

Type access

0168H Total Harmonic Distortion of V1 or V12, THD_V1 0~10000 word R

0169H Total Harmonic Distortion of V2 or V23, THD_V2 0~10000 word R

016AH Total Harmonic Distortion of V3 or V31, THD_V3 0~10000 word R

016BH Average Total Harmonic Distortion of Voltage,THD_V 0~10000 word R

016CH Total Harmonic Distortion of I1 , THD_I1 0~10000 word R

016DH Total Harmonic Distortion of I2, THD_I2 0~10000 word R

016EH Total Harmonic Distortion of I3, THD_I3 0~10000 word R

016FH Average Total Harmonic Distortion of Current, THD_I 0~10000 word R

0170H-

018DH Harmonic Content of V1 or V12 (2nd to 31st) 0~10000 word R

018EH Total Odd Harmonic Distortion of V1 or V12 0~10000 word R

018FH Total Even Harmonic Distortion of V1 or V12 0~10000 word R

0190H Crest factor of V1 or V12 0~65535 word R

0191H Telephone interference factor of V1 or V12, THFF 0~10000 word R

0192H-

01AFH Harmonic Content of V2 or V23 (2nd to 31st) 0~10000 word R

01B0H Total Odd Harmonic Distortion of V2 or V23 0~10000 word R

Table 4.17 Energy data converting table
