01B1H Total Even Harmonic Distortion of V2 or V23 0~10000 word R
01B2H Crest factor of V2 or V23 0~65535 word R
01B3H Telephone interference factor of V2 or V23, THFF 0~10000 word R
01B4H-
01D1H Harmonic Content of V3 or V31 (2
nd
to 31
st
) 0~10000 word R
01D2H Total Odd Harmonic Distortion of V3 or V31 0~10000 word R
01D3H Total Even Harmonic Distortion of V3 or V31 0~10000 word R
01D4H Crest factor of V3 or V31 0~65535 word R
01D5H Telephone interference factor of V3 or V31, THFF 0~10000 word R
01D6H-
01F3H Harmonic Content of I1 (2
nd
to 31
st
) 0~10000 word R
01F4H Total Odd Harmonic Distortion of I1 0~10000 word R
01F5H Total Even Harmonic Distortion of I1 0~10000 word R
01F6H K Factor of I1 0~65535 word R
01F7H-
0214H Harmonic Content of I2 (2
nd
to 31
st
) 0~10000 word R
0215H Total Odd Harmonic Distortion of I2 0~10000 word R
0216H Total Even Harmonic Distortion of I2 0~10000 word R
0217H K Factor of I2 0~65535 word R
0218H-
0235H Harmonic Content of I3 (2
nd
to 31
st
) 0~10000 word R
0236H Total Odd Harmonic Distortion of I3 0~10000 word R
0237H Total Even Harmonic Distortion of I3 0~10000 word R
0238H K Factor of I3 0~65535 word R
The Relationship between numerical value in register of Ai205 and the physical
value is as following table. (Rx is the numerical value inregister of Ai205)
75
Parameter Relationship Unit
THD THD=Rx / 10000 × 100% NA
Harmonic Content HDn=Rx / 10000 × 100% NA
