AMPTRON Ai205 - Data Address Table

To Next Page

To Previous Page

Address Parameter Range Object Type Type of access

0130H Frequency F 0~7000 word R

0131H Phase Voltage V1 0~65535 word R

0132H Phase Voltage V2 0~65535 word R

0133H Phase Voltage V3 0~65535 word R

0134H Average Phase Voltage Vlnavg 0~65535 word R

0135H Line Voltage V12 0~65535 word R

0136H Line Voltage V23 0~65535 word R

0137H Line Voltage V31 0~65535 word R

0138H Average Line Voltage Vllavg 0~65535 word R

0139H Current I1 0~65535 word R

013AH Current I2 0~65535 word R

013BH Current I3 0~65535 word R

013CH Average Current Iavg 0~65535 word R

013DH Neutral Line Current In 0~65535 word R

013EH Phase Power P1 -32768~32767 Integer R

013FH Phase Power P2 -32768~32767 Integer R

0140H Phase Power P3 -32768~32767 Integer R

0141H System Power Psum -32768~32767 Integer R

0142H Phase Reactive Power Q1 -32768~32767 Integer R

0143H Phase Reactive Power Q2 -32768~32767 Integer R

0144H Phase Reactive Power Q3 -32768~32767 Integer R

Data address table

The measured data in shadow only exists in Ai205-P2 or -P3.

Basic Analog measurements

Function code: 03
