0107H PT2 100~400 word R/W

0108H CT1 5~10000 word R/W

0109H DO type 0:Pulse Output

1:Alarm Output word R/W

010AH Energy Variable Number

associated with DO1 0~8 word R/W

010BH Energy Variable Number

associated with DO2 0~8 word R/W

010CH Pulse Width 1~50 word R/W

010DH Pulse Rate 1~6000 word R/W

010EH Relay1 Working Mode 0: Latch

1: Momentary word R/W

010FH Relay1 Pulse Width 50~3000 word R/W

0110H Relay2 Working Mode 0: Latch

1: Momentary word R/W

0111H Relay2 Pulse Width 50~3000 word R/W

0112H LCD Back light Time 0~120 word R/W

0113H Demand Slid Window Time 1~30 word R/W

0114H Max/Min Clean 0ah word R/W

Table 4.25 System parameter address

Status Input (DI)

Function code: 03 for Reading, 16 for Presetting

Addr. Parameter Range Object Type Type of access

0000H DI1 1 :ON , 0 :OFF bit R

0001H DI2 1 :ON , 0 :OFF bit R

0002H DI3 1 : ON, 0 :OFF bit R

0003H DI4 1 :ON, 0 : OFF bit R

Table 4.26 Digital input(DI) address
