Amtech Axpert-Eazy Series - Page 160

Amtech
6-114
6
Sr.
No.
Command
Name
Op
-
Code
DATA1
DATA2
DATA3
Description
30 NEG 030 Register (n) 000 000 Negative. Register (n) = - Register (n)
31 ABS 031 Register (n) 000 000 Absolute the value of Register (n). Register (n) =
ABS (Register (n))
32 CMP_GT 035 Flag (n) Register
(n)
Register
(m)
If Register (n) is greater than Register (m) then given
Flag (n) is set.
33 CMP_LT 036 Flag (n) Register
(n)
Register
(m)
If Register (n) is less than Register (m) then given
Flag (n) is set.
34 CMP_GE 037 Flag (n) Register
(n)
Register
(m)
If Register (n) is greater than or equal to Register (m)
then given Flag (n) is set.
35 CMP_LE 038 Flag (n) Register
(n)
Register
(m)
If Register (n) is less than or equal to Register (m)
then given Flag (n) is set.
36 CMP_EQ 039 Flag (n) Register
(n)
Register
(m)
If Register (n) is equal to Register (m) then given
Flag (n) is set.
37 CMP_NE 040 Flag (n) Register
(n)
Register
(m)
If Register (n) is not equal to Register (m) then given
Flag (n) is set.
38 IF 041 Flag (n) 000 000 If given Flag (n) is set then condition is true and
execute IF routine until ELSE or END_IF.
39 ELSE 042 000 000 000 If IF condition is false then ELSE loop will execute
until END_IF.
40 END_IF 043 000 000 000 Specify the end of IF and ELSE Loop.
41 JUMP 044 X (1-100) 000 000 JUMP to X command no.
42 READ_PSO 046 Flag (n) 1-7 000 Read the status of selected PSO (1-7) in selected
Flag (n).
43 READ_PSI 047 Flag (n) 1-8 000 Read the status of selected PSI (1-8) in selected
Flag (n).
44 WRITE_PSI 048 1-25 Flag (n) 000 Assign value of Flag (n) in PSI function (1-25).
45 WRITE_PSO 049 1-7 Flag (n) 000 Assign value of Flag (n) in PSO (1-7).
46 READ_MON_PA
RA
050 Register (n) 0-115 000 Read the value of monitor parameter (0-115) in
Register (n).
47 READ_STA_BIT 051 Flag (n) 1-2 0-15 Read the value of status bit (0-15) of status register
(1-2) in Flag (n).
48 READ_FLT_BIT 052 Flag (n) 1-5 0-15 Read the value of fault bit (0-15) of fault register (1-5
)
in Flag (n).
49 READ_CWORD
_BIT
053 Flag (n) 1-2 0-15 Read the value of control bit (0-15) of control word
(1-2) in Flag (n).
50 WRITE_AN_O/P 054 1-4 Register
(n)
000 Assign the value of Register (n) to selected Analog
O/P (1-4). i.e 1000d = 10V.
51 TIMER1 057 000 000 000
Input = Flag no 92
Output = Flag no 93
Count = C701 * C702 ms
Count in multiple of 1ms. Maximum Timer 298 Hour.
52 TIMER2 058 000 000 000
Input = Flag no 94
Output = Flag no 95
Count = C703 * C704 ms
Count in multiple of 1ms. Maximum Timer 298 Hour.
53 TIMER3 059 000 000 000 Input = Flag
no 96
Output = Flag no 97
Count = C705 * C706 ms
Count in multiple of 1ms. Maximum Timer 298 Hour.
54 TIMER4 060 000 000 000 Input = Flag no 98
Output = Flag no 99
Count = C707 * C708 ms
Count in multiple of 1ms. Maximum Timer 298 Hour.
55 DISPLAY_REG 061 X1 (1-10) Register
(n)
000 It will display the value of Register (n) to selected
display number. It will be stored in EEPROM on
Power off mode.
