Programming
141
NI-3101-SIG Signature Series NetLinx Integrated Controller
In your terminal program, type "Help" or a question mark ("?") and <Enter> to display the Configuration
Port commands listed in the following table.
Configuration Port Commands
Command Description
DATE Displays the current date and day of the week.
Example:
>DATE
10/31/2004 Wed
DEVICE HOLDOFF ON|OFF Sets the Master to holdoff devices and not allow them to report online until
the NetLinx program has completed executing the DEFINE_START
section.
Example:
>Device Holdoff ON
Device Holdoff Set.
This command sets the state of the device holdoff. The GET DEVICE
HOLDOFF command reveals whether the state is On or Off.
DEVICE STATUS <D:P:S> Displays a list of all active (on) channels for the specified D:P:S. Enter
DEVICE STATUS without the D:P:S variable, the Master displays ports,
channels, and version information.
Displays status of the specified Master.
Example (on a local Master):
>Device 0 AMX Corp.,NI-2000,v3.00.312 contains 1 Ports.
Port 1 - Channels:256 Levels:8
MaxStringLen=64 Types=8 bit MaxCommandLen=64 Types=8
bit
The following input channels are on:None
The following output channels are on:None
The following feedback channels are on:None
Level 1=0 Supported data types=UByte,UInt
Level 2=0 Supported data types=UByte,UInt
Level 3=0 Supported data types=UByte,UInt
Level 4=0 Supported data types=UByte,UInt
Level 5=0 Supported data types=UByte,UInt
Level 6=0 Supported data types=UByte,UInt
Level 7=0 Supported data types=UByte,UInt
Level 8=0 Supported data types=UByte,UInt
DISK FREE Displays the total bytes of free space available on the Master.
Example:
>DISK FREE
The disk has 2441216 bytes of free space.
DNS LIST <D:P:S> Displays:
• Domain suffix·
• Configured DNS IP Information
Example:
>DNS LIST [0:1:0]
Domain suffix:amx.com
The following DNS IPs are configured
Entry 1-192.168.20.5
Entry 2-12.18.110.8
Entry 3-12.18.110.7
ECHO OFF Disables terminal character's echo (display) function.
ECHO ON Enables terminal character's echo (display) function.
GET DEVICE HOLDOFF Displays the state of the device holdoff setting in the Master.
Example:
>GET DEVICE HOLDOFF
Device Holdoff is off.
This command reveals the state of the device holdoff set using the
DEVICE HOLDOFF ON|OFF command.
