NI-3101-SIG Signature Series NetLinx Integrated Controller
Configuration Port Commands (Cont.)
Command Description
SHOW SYSTEM Provides a list of all devices in all systems currently on-line. The systems
lists are either directly connected to this Master (i.e. 1 hop away), or are
referenced in the DEFINE_DEVICE section of the NetLinx program.
Optionally, you may provide the desired system number as a parameter to
display only that system's information (e.g. SHOW SYSTEM 2001). The
systems listed are in numerical order.
Example:
>SHOW SYSTEM
Local devices for system #50 (This System)
------------------------------------------------------------
Device (ID)Model (ID)Mfg FWID Version
00000 (00256)Master (00001)AMX Corp. 00256 v2.10.75
(PID=0:OID=0) Serial='2010-12090',0,0,0,0,0,0
Physical Address=NeuronID 000239712501
(00256)vxWorks Image (00001) 00257 v2.00.77
(PID=0:OID=1) Serial=N/A
(00256)BootROM (00001) 00258 v2.00.76
(PID=0:OID=2) Serial=N/A
(00256)AXlink I/F uContr(00001) 00270 v1.02
(PID=0:OID=3) Serial=0000000000000000
00096 (00192)VOLUME 3 CONTROL BO(00001)AMX Corp. 00000 v2.10
(PID=0:OID=0) Serial=0000000000000000
Physical Address=Axlink
00128 (00188)COLOR LCD TOUCH PAN(00001)AMX Corp. 32778 v5.01d
(PID=0:OID=0) Serial=0000000000000000
Physical Address=Axlink
05001 (00257)NXI Download (00001)AMX Corp. 00260
v1.00.20
(PID=0:OID=0) Serial=0,0,0,0,0,0,0,0,0,0,0,0,
Physical Address=NeuronID 000189145801
(00257)NXI/NXI-1000 Boot(00001) 00261 v1.00.00
(PID=0:OID=1) Serial=0,0,0,0,0,0,0,0,0,0,0,0,
10002 (00003)PHAST PLK-IMS (00001)Phast Corp. 0003 v3.12
(PID=0:OID=0) Serial=0000000000000000
Physical Address=NeuronID 0100417BD800
TCP LIST Lists all active TCP/IP connections.
Example:
>TCP LIST
The following TCP connections exist(ed):
1: IP=192.168.21.56:1042 Socket=0 (Dead)
2: IP=192.168.21.56:1420 Socket=0 (Dead)
TIME Displays the current time on the Master.
Example:
>TIME
13:42:04
URL LIST <D:P:S> Displays the list of URL addresses programmed in the Master (or another
system).
Example:
>URL LIST
The following URLs exist in the URL connection list
->Entry 0-192.168.13.65:1319 IP=192.168.13.65 State=Connected
Entry 1-192.168.13.200:1319 IP=192.168.13.200 State=Issue Connect
