Analytik Jena qTOWER3 touch - 10.2 Standards and Directives

qTOWER
3
touch/qTOWER
3
G touch Specifications
39
Supported plastic products 96-well micro titer plates with optical film
8-well strips 0.2 ml with optical lids
0.2 ml individual vessels with optical lids
Sensitivity 1 nmol/l FAM at 30µl sample volume in a 96-well PCR
plate
Measuring time 96-well plate (single measurement, 6 colors)
approx. 6 s
Measuring range ±130 000 (±17 bit)
Dynamic range 10 log stages
Light source Four high-intensity LEDs (blue, green, white, red)
Detector Photo Multiplier (PMT)
Color filter modules Color modules for all frequently used real-time PCR dyes
Color module 1 Blue (470 nm/520 nm)
Color module 2 Green (515 nm/545 nm)
Color module 3 Yellow (535 nm/580 nm)
Color module 4 Orange (565 nm/605 nm)
Color module 5 Red (630 nm/670 nm)
Color module 6 NIR 1(660 nm/705 nm)
Color module sypro (490 nm/580 nm)
FRET filter combinations:
FRET module 1 (470 nm/580 nm)
FRET module 2 (470 nm/670 nm)
FRET module 3 (470 nm/705 nm)
FRET module 4 (515 nm/670 nm)
FRET module 5 (470 nm/605 nm)
Software and tablet PC
qPCRsoft touch Control and analysis program
Export functions Excel, CSV, LIMS
Tablet PC 10", color touch display for graphical controlling
Data connection USB port for data export via USB stick
Operating system Win 10
10.2 Standards and directives
The qTOWER³ touch features protection class I. The casing features protection type IP
20.
The qTOWER³ touch complies with the safety standards
 EN 61010-1:2010
 UL 61010-1:2012
 CAN/CSA-C22.2 No. 61010-1-12:2012
Safety class and safety
type
Device safety
