7.9. Halogen lamp replacement
To replace the halogen lamp, follow the instruction below:
1. halogen lamp transformer primary 230 V ~ , secondary 12 V ~, halogen lamp
protection fuse on the power board 250 mA (picture 1);
2. to replace the lamp, unscrew the glass fixing nuts into the chamber (picture 2);
3. under the right hand panel it is possible to work on the lamp holder and the plug
(picture 3).
