4.9. Gas conversion
All equipment is tested and adjusted to work with Natural gas (G20), where it is required to
use a propane gas, follow the instruction below:
1. Gas nozzle replacement: Unscrew the gas pipe (Photo 1), remove the Natural gas
(G20) nozzle and put in place the replacement nozzle (photo 2), then tighten the
pipe. The nozzle works also as seal.
The nozzle must be mounted as shown in photo 3.
Injectors
FX61G3 FX101G3 FX82G3
G20 Ø635 - 3147120 Ø605 - 3141800 Ø635 - 3147120
G31 Ø465 - 3141630 Ø485 - 3153010 Ø485 - 3153010
Injectors
FX122G3 FX201G3 FX202G3
G20 Ø640 - 3147130 Ø640 - 3147130 Ø615 - 3141820
G31 Ø500 - 3167720 Ø465 - 3141630 Ø480 - 3153000
2. Setting the type of gas on the display:
o enter menu “Service” (Password:SAAP),
o enter menu “Setup gas”(Password:SI74),
o select the type of gas used from the menu “Type of gas”
3. Perform analysis of flue gas (see section 4.6)
