3. ELECTRONIC BOARDS FOR LEVELS 2-3, INVERTER,
FUSES, OVERLOAD RELAYS
3.1. Electronic boards level 3 general layout
The electronic boards system comprises:
1. panel group:
o CPU board 1a
o display LCD board 1b
o keyboard (glued to the glass panel) 1c
o LED board 1d
2. power PCB
3. combustion and fan control PCBs (only gas model)
4. inverter
5. USB connector
6. transformer
7. on/off switch
