Angelo Po FX201E2 - Page 31

Copyright by Servizio Clienti ANGELO PO Spa
31
Inverter alarm table
E06:41
between phases a UV excess current
flows
check the correct connection of the motor and
that the phases U and V of the motor power
supply are not short circuited together
E06:42
between phases a UW excess current
flows
check the correct connection of the motor and
that the phases U and W of the motor power
supply are not short circuited together
E06:43
between phases a VW excess current
flows
check the correct connection of the motor and
that the phases V and W of the motor power
supply are not short circuited together
E06:63
E06:64
Overcurrent limits exceeded
High current limit exceeded 150%
for 1 minute or 200% for 3 seconds
check that the motor is free to move and doesn’t
touch any other item
E06:70
inverter power section faulty
Check if the inverter data voltage and verify the
power supply (120V / 208-240V /480V AC). If
necessary replace the inverter.
E06:71
Excessive communication errors
Check if the cable connecting the serial BUS line
is properly connected and/or take away from
other voltage wires.
E06:81
Communication loss
Check if the cable connecting the serial BUS line
is properly connected and/or take away from
other voltage wires.
E06:100
Inverter checksum error Replace the inverter
E06:122
Inverter control section faulty Replace the inverter
E06:255
Inverter blocked
check the connection between terminal 1 and
terminal 11 on the inverter.
