Copyright by Servizio Clienti ANGELO PO Spa
84
NON RETURN
VALVE
PRESSURE
REDUCER
WATER SOLENOID
VALVE
MANOMETER
PRESS. SWITCH
MIXING TANK
DRAINAGE
SOLENOID VALVE
DETERGENT
DISPENSER
SANITIZER
DISPENS
ER
TO SIPHON
TO THE
SPRINKLERS
WATER INLET
WATER DRAIN
LEVEL
SENSOR
