Animo OptiFresh - Page 15

05/2008 Rev. 0.6
55
Service menu continued ….
Main item Sub item Sub Item Range Description
2.3 Recipe setting
(continued…)
Recipe name 1
Recipe name 12
DV 4 WT 0,0-30,0 s Waiting time Water 4
DV 4 0,0-100,0 ml
Dispensing amount Water 4
(Hot water dispensed)
DV 5 WT 0,0-30,0 s Waiting time Water 5
DV 5 0,0-100,0 ml
Dispensing amount from an extra hot water
valve Water 5 (reserved for a Brewer
By-Pass option).
DV 6 WT 0,0-30,0 s Waiting time Water 6
DV 6 0,0-100,0 ml
Dispensing amount from an extra inlet
valve Water 6 (Cold Water option)
Strength Coffee 0-50% Use the strength setting item to add an
ingredient to the strength adjustment.
Ingredient strength adjustment:
0= off / > 1 = on
Example: [coffee] 20%
Example: [cocoa] 40%
Strength Decaf 0-50%
Strength Chocolate 0-50%
Strength Topping 0-50%
Strength Sugar 0-50%
Strength Ingrediënt 6
Option
0-50%
Strength
-- - 0 + ++
-20% -10% 0 10% 20%
Strength
-- - 0 + ++
-40% -20% 0 20% 40%
