6. COMPONENT ACCESSIBILITY
Water reservoir
Boil dry safety
Level / NTC
Control unit
Drip tray full sensor
Inlet valve
Door switch
Waste bin sens
o
Main switch
Brewer motor
Power relay
24V power sup
p
Ventilator
Ingredient motors
Dispensing valves
Display
Key switch
Service panel
Circuit board
Brewer
Fig. 15
