Next, let's test these important connections. Using your multimeter's Continuity setting, verify the
following:
IEC socket ground to Chassis Ground
IEC socket Neutral to IEC PCB White solder tab
IEC Line (Hot) to IEC PCB Black–Grey Solder tab
Finally, peel off the paper covering on the plastic insulating board and, using the IEC hardware,
mount the IEC PCB to the back of the amplifier above the Mains transformer as shown in the
picture above: use a 30 mm M3 screw, a short standoff, then the PCB, another short standoff, and
finally the plastic insulating board and a nut.
