7.7 Installing the Power Supply Board
This is straightforward.
Add 4 M4 standoffs to the board.
Position all the wires going to — and coming from — the Power Supply board in the positions
shown below.
Install the board in the chassis by attaching it with 4 M4 screws into the standoffs from the
underside of the chassis.
That's it!
