5.3 Parts List
Quantity
Type
Designator
2
Audio Note Tantalum Non-Magnetic 220K 1W
R1, R8
2
Audio Note Tantalum Non-Magnetic 33K 2W
R2, R9
2
Audio Note Tantalum Non-Magnetic 100K 1W
R3, R10
2
Audio Note Tantalum Non-Magnetic 10K 1W
R4, R12
2
Audio Note Tantalum Non-Magnetic 10K 1W
R5, R11
2
Audio Note Tantalum Non-Magnetic 220R 1W
R6, R13
2
Audio Note Tantalum Non-Magnetic 100K 2W
R7, R14
4
Audio Note .22uf 630V Copper Foil Mylar in Oil Capacitors
C1, C4, C5, C8
2
100uf 450V Rubycon Electrolytic Capacitors
C2, C6
2
470uf 16V ELNA SILMIC II Electrolytic Capacitors
C3, C7
2
6SH7 Driver Tubes
V1, V2
2
8-pin Valve Bases
1
Driver PCB
5.4 Installing the Valve Bases
We'll begin by installing the 2 8-pin valve bases for the 6SH7 driver tubes.
As before, you'll want to make sure to use masking tape to secure the valve bases to the board prior
to soldering to make sure they are level. It's a good idea to review the tips we offered in the Power
Supply installation section.
Install the 8-pin valve bases in positions V1 and V2. Be very careful to align the tab 'cut-outs' on
the top of the valve bases with the tab stencils on the board. Take your time soldering on the
underside of the board as they will require a fair bit of heat and solder to adhere the pins to the
board. Again, no rushing!
