10.3 Connecting the Speaker Posts
Put a puddle of solder in the center of each speaker post.
Both the EI-Core and the C-Core output transformers have three colored wires on the Secondary:
 Green is Ground
 Blue is the 4 ohm tap
 Purple is the 8 ohm tap
