Figure: Install conduits when adding a second column.
Step 5: Mount modules onto the brackets.
Hang the first battery module onto the mount bracket and fasten the module to the baseplate.
When securing the module interlockers, make sure that the inner edges of the baseplate and all the modules are
aligned within a tolerance of 1 mm.
